| Type |
Digital, single-lens reflex, AF / AE camera |
| Recording Media |
CF card (Type I, UDMA mode 7-compatible), SD memory card, SDHC memory card, SDXC memory card |
| Image sensor size |
Approx. 36 x 24mm |
| Compatible Lenses |
Canon EF lenses (except EF-S lenses)
(35 mm-equivalent lens focal length will be as indicated on the lens) |
| Lens Mount |
Canon EF mount |
|
|
| Type |
CMOS sensor |
| Effective Pixels |
Approx. 22.30 megapixels |
| Aspect Ratio |
3:2 |
| Dust Delete Feature |
Auto, Manual, Dust Delete Data appending |
|
|
| Recording Format |
Design rule for Camera File System 2.0 |
| Image Type |
JPEG, RAW (14-bit Canon original), RAW + JPEG simultaneous recording enabled |
| Recording Pixels |
L (Large): |
Approx. 22.10 megapixels (5760 x 3840) |
| M (Medium): |
Approx. 9.80 megapixels (3840 x 2560) |
| S1 (Small 1): |
Approx. 5.50 megapixels (2880 x 1920) |
| S2 (Small 2): |
Approx. 2.50 megapixels (1920 x 1280) |
| S3 (Small 3): |
Approx. 350,000 pixels (720 x 480) |
| RAW: |
Approx. 22.10 megapixels (5760 x 3840) |
| M-RAW: |
Approx. 10.50 megapixels (3960 x 2640) |
| S-RAW: |
Approx. 5.50 megapixels (2880 x 1920) |
| Recording function |
Standard, Auto switch card, Rec. separately, Rec. to multiple |
| Create / Select a Folder |
Possible |
| File name |
Preset code, User setting 1, User setting 2 |
| File numbering |
Continuous, auto reset, manual reset |
|
|
| Picture Style |
Auto, Standard, Portrait, Landscape, Neutral, Faithful, Monochrome, User Def. 1 - 3 |
| White Balance |
Auto, Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom, Colour temperature setting (Approx. 2500 - 10000K), White balance correction, and White balance bracketing possible
* Flash colour temperature information transmission enabled |
| Noise Reduction |
Applicable to long exposures and high ISO speed shots |
| Automatic Image Brightness Correction |
Auto Lighting Optimizer |
| Highlight Tone Priority |
Provided |
| Lens Peripheral Illumination Correction |
Peripheral illumination correction, Chromatic aberration correction |
|
|
| Type |
Eye-level pentaprism |
| Coverage |
Vertical / Horizontal Approx. 100% (with Eye point Approx. 21mm) |
| Magnification |
Approx. 0.71x (-1m-1 with 50mm lens at infinity) |
| Eyepoint |
Approx. 21mm (from eyepiece lens center at -1m-1) |
| Build-in Dioptric adjustment |
Approx. -3.0 - +1.0m-1 (dpt) |
| Focusing Screen |
Fixed |
| AF status indicator |
Provided |
| Grid display |
Provided |
| Electronic level |
Horizontal: |
1° increments, ±6° |
| Vertical: |
1° increments, ±4° |
| * During horizontal shooting |
| Mirror |
Quick-return type |
| Depth-of-field Preview |
Provided |
|
|
| Type |
TTL secondary image-registration, phase detection |
| AF Points |
61 points (Up to 41 cross-type points)
* Number of available AF points and cross-type points vary depending on the lens. |
| Focusing Brightness Range |
EV -2 - 18 (with center f/2.8 AF point, 23°C / 73°F, ISO 100) |
| Focusing Modes |
One-Shot AF, AI Servo AF, AI Focus AF, Manual focusing (MF) |
| AF Area Selection Modes |
Single-point Spot AF (manual selection), Single-point AF (manual selection), AF point expansion (manual selection; up, down, left, and right), AF point expansion (manual selection; surround), Zone AF (manual selection), Auto selection of 61 AF points |
| AF Configuration Tool |
Case 1 - 6 |
| AI Servo Characteristics |
Tracking sensitivity, Acceleration / deceleration tracking, AF point auto switching |
| AF Fine Adjustment |
AF Microadjustment (All lenses by same amount or Adjust by lens) |
| AF-assist Beam |
Emitted by the EOS-dedicated external Speedlite |
|
|
| Metering Modes |
63-zone TTL full-aperture metering
| • |
Evaluative metering (linked to all AF points) |
| • |
Partial metering (Approx. 6.2% of viewfinder at center) |
| • |
Spot metering (Approx. 1.5% of viewfinder at center) |
| • |
Center-weighted average metering |
|
| Metering Range |
EV 1 - 20 (at 23°C / 73°F with EF50mm f/1.4 USM lens, ISO 100) |
| Exposure Control |
Program AE (Scene Intelligent Auto, Program), Shutter-priority AE, Aperture-priority AE, Manual exposure, Bulb exposure |
| ISO Speed (Recommended exposure index) |
Scene Intelligent Auto: ISO 100 - 12800 set automatically P, Tv, Av, M, B: Auto ISO, ISO 100 - 25600 (in 1/3- or whole-stop increments), or ISO expansion to L (50), H1 (equivalent to ISO 51200), H2 (equivalent to ISO 102400) |
| ISO Speed Settings |
ISO speed range, Auto ISO range, and Auto ISO minimum shutter speed settable |
| Exposure Compensation |
Manual: |
±5 stops in 1/3- or 1/2-stop increments |
| AEB: |
±3 stops in 1/3- or 1/2-stop increments (Can be combined with manual exposure compensation) |
| AE Lock |
Auto: |
Applied in One-Shot AF mode with evaluative metering when focus is achieved |
| Manual: |
By AE lock button |
|
|
| Dynamic Range Adjustment |
Auto, ±1 EV, ±2 EV, ±3 EV |
| Effect |
Natural, Art standard, Art vivid, Art bold, Art embossed |
| Auto Image Align |
Possible |
|
|
| Shooting Method |
Function / control priority, Continuous shooting priority |
| No. of Multiple Exposures |
2 to 9 exposures |
| Multiple-Exposure Control |
Additive, Average, Bright, Dark |
|
|
| Type |
Electronically-controlled, focal-plane shutter |
| Shutter Speeds |
1/8000sec. to 1/60sec. (Scene Intelligent Auto mode), X-sync at 1/200sec.
* With a wide-angle lens, the shutter speed may be 1/60sec. or slower.
1/8000sec. to 30secs., bulb (Total shutter speed range. Available range varies by shooting mode.) |
|
|
| Drive Modes |
Single shooting, High-speed continuous shooting, Low-speed continuous shooting, Silent single shooting, Silent continuous shooting, 10secs. self-timer / remote control, 2secs. self-timer / remote control |
| Continuous Shooting Speed |
High-speed continuous shooting: |
Max. Approx. 6 shots/sec. |
| Low-speed continuous shooting: |
Max. Approx. 3 shots/sec. |
| Silent continuous shooting: |
Max. Approx. 3 shots/sec. |
| Max. Burst |
JPEG Large / Fine: |
Approx. 65 shots (Approx. 16270 shots) |
| RAW: |
Approx. 13 shots (Approx. 18 shots) |
| RAW + JPEG Large / Fine: |
Approx. 7 shots (Approx. 7 shots) |
* Figures are based on Canon's testing standards (ISO 100 and Standard Picture Style) and a 8GB card.
* Figures in parentheses apply to an UDMA mode 7, 128GB card based on Canon's testing standards. |
|
|
| Compatible Speedlites |
EX-series Speedlites |
| Flash Metering |
E-TTL II autoflash |
| Flash Exposure Compensation |
±3 stops in 1/3- or 1/2-stop increments |
| FE Lock |
Provided |
| PC Terminal |
Provided |
| External Speedlite control |
Provided
* Compatible with radio wireless flash photography. |
|
|
| Shooting Modes |
3:2, 4:3, 16:9, 1:1 |
| Focusing Modes |
Live mode, Face detection Live mode (contrast detection), Quick mode (phase-difference detection), Manual focusing (Approx. 5x / 10x magnification possible) |
| Focusing brightness range |
EV 1 - 18 (with contrast detection, at 23°C / 73°F, ISO 100) |
| Metering Modes |
Evaluative metering with the image sensor |
| Metering Range |
EV 0 - 20 (at 23°C / 73°F with EF50mm f/1.4 USM lens, ISO 100) |
| Silent Shooting |
Provided (Mode 1 and 2) |
| Three Types |
Three types |
|
|
| Movie Recording Compression |
MPEG-4 AVC / H.264
Variable (average) bit rate |
| Audio Recording Format |
Linear PCM |
| Recording Format |
MOV |
| Recording Size And Frame Rate |
1920 x 1080 (Full HD): |
30p / 25p / 24p |
| 1280 x 720 (HD): |
60p / 50p |
| 640 x 480 (SD): |
30p / 25p |
| * 30p: 29.97fps, 25p: 25.00fps, 24p: 23.976fps, 60p: 59.94fps, 50p: 50.00fps |
| Compression Method |
ALL-I (I-only), IPB |
| File size |
1920 x 1080
(30p / 25p / 24p) / IPB: |
Approx. 235MB/min. |
1920 x 1080
(30p / 25p / 24p) / ALL-I : |
Approx. 685MB/min. |
1280 x 720
(60p / 50p) / IPB: |
Approx. 205MB/min. |
1280 x 720
(60p / 50p) / ALL-I: |
Approx. 610MB/min. |
640 x 480
(30p / 25p) / IPB: |
Approx. 78MB/min. |
* Card reading / writing speed necessary for movie shooting:
CF card: IPB: at least 10MB per sec. / ALL-I: at least 30MB per sec.
SD card: IPB: at least 6MB per sec. / ALL-I: at least 20MB per sec. |
| Focus Modes |
Same as focusing with Live View shooting |
| Metering Modes |
Center-weighted average and Evaluative metering with the image sensor
* Automatically set by the focusing mode. |
| Metering Range |
EV 0 - 20 (at 23°C / 73°F with EF50mm f/1.4 USM lens, ISO 100) |
| Exposure Control |
1. Autoexposure,
2. Shutter-priority AE,
3. Aperture-priority AE,
4. Manual exposure
* With 1, 2, and 3, exposure compensation and AE lock are possible (except in Scene Intelligent Auto mode). |
| Exposure compensation |
±3 stops in 1/3-stop increments (±5 stops for still photos) |
ISO speed
(Recommended exposure index) |
Scene Intelligent Auto and Tv: Automatically set within ISO 100 - 12800
P, Av, and B: Automatically set within ISO 100 – 12800 expandable to H (equivalent to ISO 25600)
M: Auto ISO (automatically set within ISO 100 - 12800), ISO 100 - 12800 set manually (in 1/3- or whole-stop increments), expandable to H (equivalent to ISO 16000 / 20000 / 25600) |
| Time Code |
Supported |
| Drop Frames |
Compatible with 60p / 30p |
| Sound Recording |
Built-in monaural microphone, external stereo microphone terminal provided
Sound recording level adjustable, wind filter provided |
| Headphones |
Headphone terminal provided |
| Grid Display |
Three types |
| Still Photos |
Possible |
|
|
| Type |
TFT colour, liquid-crystal monitor |
| Monitor Size and Dots |
Wide, 8.1 cm (3.2-in.) (3:2) with Approx. 1.04 million dots |
| Brightness Adjustment |
Auto (Dark, Standard, Bright), Manual (7 levels) |
| Electronic Level |
Horizontal: |
1° increments, ±6° |
| Vertical: |
1° increments, ±4° |
| Interface Languages |
25 |
| Feature Guide |
Displayable |
|
|
| Image Display Formats |
Single image display, Single image + Info display (Basic info, shooting info, histogram), 4-image index, 9-image index, 2-image display |
| Highlight Alert |
Overexposed highlights blink |
| AF Point Display |
Possible |
| Grid Display |
Three types |
| Zoom Magnification |
Approx. 1.5x - 10x, starting magnification and position settable |
| Image Browsing Methods |
Single image, jump by 10 or 100 images, by shooting date, by folder, by movies, by stills, by rating |
| Image Rotate |
Possible |
| Ratings |
Provided |
| Movie Playback |
Enabled (LCD monitor, video / audio OUT, HDMI OUT), built-in speaker |
| Slide Show |
All images, by date, by folder, movies, stills, or by rating |
| Image protect: |
Possible |
| Copying images |
Possible |
|
|
| In-camera RAW Image Processing |
Brightness correction, White balance, Picture Style, Auto Lighting Optimizer, High ISO speed noise reduction, JPEG image-recording quality, Colour space, Peripheral illumination correction, Distortion correction, and Chromatic aberration correction |
| Resize |
Possible |
|
|
| Compatible Printers |
PictBridge-compatible printers |
| Printable Images |
JPEG and RAW images |
| Print Ordering |
DPOF Version 1.1 compatible |
|
|
| Transferrable Images |
Still photos (JPEG, RAW, RAW + JPEG images), Movies |
|
|
| Custom Functions |
13 |
| My Menu Registration |
Possible |
| Custom Shooting Modes |
Register under Mode Dial's C1 / C2 / C3 |
| Copyright Information |
Entry and inclusion enabled |
|
|
| Audio / Video OUT/ Digital Terminal |
Analog video (Compatible with NTSC / PAL) / stereo audio output
Personal computer communication, Direct printing (Hi-Speed USB or equivalent), Wireless File Transmitter WFT-E7, GPS Receiver GP-E2 connection |
| HDMI mini OUT terminal |
Type C (Auto switching of resolution), CEC-compatible |
| External Microphone IN Terminal |
3.5mm stereo mini-jack |
| Headphone terminal |
3.5mm stereo mini-jack |
| Remote Control Terminal |
Compatible with N3-type remote controller |
| Wireless Remote Control |
Remote Controller RC-6 |
| Eye-Fi card |
Compatible |
|
|
| Battery |
Battery Pack LP-E6 (Quantity 1)
* AC power can be supplied via AC Adapter Kit ACK-E6.
* With Battery Grip BG-E11 attached, size-AA/LR6 batteries can be used. |
| Battery Information |
Remaining capacity, Shutter count, Recharge performance, and Battery registration possible |
| Battery Life (Based on CIPA testing standards) |
With viewfinder shooting: |
Approx. 950 shots at 23°C / 73°F, Approx. 850 shots at 0°C / 32°F |
| With Live View shooting: |
Approx. 200 shots at 23°C / 73°F, Approx. 180 shots at 0°C / 32°F |
| Movie Shooting Ttime |
Approx. 1hr. 30mins. at 23°C / 73°F
Approx. 1hr. 20mins. at 0°C / 32°F
(with fully-charged Battery Pack LP-E6) |
| Date / Time Battery |
CR1616 lithium battery (Quantity 1) |
|
|
| Dimensions (W x H x D) |
Approx. 152.0 x 116.4 x 76.4mm / 6.0 x 4.6 x 3.0in. |
| Weight |
Approx. 950g / 33.5oz. (CIPA Guidelines),
Approx. 860g / 30.3oz. (Body only) |
|
|
| Working Temperature Range |
0°C - 40°C / 32°F - 104°F |
| Working Humidity |
85% or less |
|
|
| Type |
Rechargeable lithium-ion battery |
| Rated Voltage |
7.2 V DC |
| Battery Capacity |
1800 mAh |
| Dimensions (W x H x D) |
Approx. 38.4 x 21.0 x 56.8mm / 1.5 x 0.8 x 2.2in. |
| Weight |
Approx. 80g / 2.8oz. |
|
|
| Compatible Battery |
Battery Pack LP-E6 |
| Recharging Time |
Approx. 2hrs. 30mins. |
| Rated Input |
100 - 240 V AC (50 / 60 Hz) |
| Rated Output |
8.4 V DC / 1.2 A |
| Working Temperature Range |
5°C - 40°C / 41°F - 104°F |
| Working Humidity |
85% or less |
| Dimensions (W x H x D) |
Approx. 69.0 x 33.0 x 93.0mm / 2.7 x 1.3 x 3.7in. |
| Weight |
Approx. 130g / 4.6oz. |
|
|
| Compatible Battery |
Battery Pack LP-E6 |
| Power cord length |
Approx. 1m / 3.3ft. |
| Recharging Time |
Approx. 2hrs. 30mins. |
| Rated Input |
100 - 240 V AC (50 / 60 Hz) |
| Rated Output |
8.4 V DC / 1.2 A |
| Working Temperature Range |
5°C - 40°C / 41°F - 104°F |
| Working Humidity |
85% or less |
| Dimensions (W x H x D) |
Approx. 69.0 x 33.0 x 93.0mm / 2.7 x 1.3 x 3.7in. |
| Weight |
Approx. 125g / 4.4oz. (excluding power cord) |
|
|
| Angle of View |
Diagonal extent: |
84° - 23°20' |
| Horizontal extent: |
74° - 19°20' |
| Vertical extent: |
53° - 13° |
| Lens Construction |
18 elements in 13 groups |
| Minimum Aperture |
f/22 |
| Closest Focusing Distance |
0.45m / 1.48ft. (from image sensor plane) |
| Max. Magnification |
0.23x (at 105mm) |
| Field of View |
535 x 345 - 158 x 106mm / 21.1 x 13.6 - 6.2 x 4.2in. (at 0.45m) |
| Image Stabilizer |
Lens shift type |
| Filter Size |
77mm |
| Lens Cap |
E-77U |
| Max. Diameter x Length |
83.5 x 107mm / 3.3 x 4.2in. |
| Weight |
Approx. 670g / 23.6oz. |
| Hood |
EW-83H |
| Case |
LP1219 |
Lihat Ukuran Penuh
